Garmin Fusion Signature Series 3 Marine Wake Tower Speakers

6.5" 230 Watt Sports Chrome  with CRGBW

DESIGNED AND ENGINEERED TO TRUE-MARINE™ STANDARDS

Built on the True-Marine design philosophy from Fusion, the Signature Series 3 wake tower speakers have an IP65 rating for protection against dust and water ingress and have been tested to a high level of protection against salt fog, temperature, vibration and UV.

THE FINEST MATERIALS AND ACOUSTIC ENGINEERING

The Signature Series 3 wake tower speakers incorporate premium materials and marine-specific design elements. This not only showcases their premium aesthetics but also their ability to produce high-quality audio while out on the water.

MULTIPLE MOUNTING ACCESSORIES

Fixed, swivel and deck mounting bracket options are available (each sold separately), allowing you to mount your Signature Series 3 wake tower speakers on board with versatility and ease.

PRECISELY CALCULATED ENCLOSURE

Specifically optimised for wake boat applications with longer throw, greater cut through and optimum air volumes, the Signature Series 3 wake tower speakers reproduce crystal clear, high-performance audio at all volume levels.

CURV CONE TECHNOLOGY

CURV is a woven fibre composite that is heat pressed to form a lighter and stronger cone. This delivers greater sound definition and higher output while providing increased protection from marine conditions.

SILK DOME TWEETER

The silk dome tweeter provides smooth upper-frequency response and increased efficiency, which delivers crystal-clear music reproduction.

LARGE-DIAMETER VOICE COIL

Delivering an increase in real power and efficiency, the large diameter voice coil provides a signature sound exclusive to the Signature Series 3 wake tower speakers.

FULLY SEALED CROSSOVER COMPONENTS

Fully sealed crossover components provide full protection from the harsh marine environment. This delivers an improved frequency response at the crossover point for a detailed audio spectrum and a new level of acoustic performance.

EXPERIENCE AN UNPRECEDENTED SPECTRUM OF COLOURS TO MATCH YOUR AUDIO.

Industry-first marine wake tower speakers with CRGBW (cool white, red, green, blue, warm white) illuminate an unprecedented spectrum of colours — from premium pastels to vibrant hues — to enhance your audio entertainment experience.

CONTROLLING THE CRGBW LIGHTING

Control the colour (static or dynamic), brightness, light mode and speed by using the optional MS-CRGBWRC wireless remote control (sold separately) or from a Garmin multifunction display via OneHelm™ integrated digital switching (lighting partner controller required).

SPORTS WHITE WAKE TOWER SPEAKERS

The Signature Series 3 sports white wake tower speakers are available in 6.5-inch size and feature industry-first CRGBW LED lighting options.

SPORTS CHROME WAKE TOWER SPEAKERS

The Signature Series 3 sports chrome wake tower speakers are available in 6.5-inch sizes and feature industry-first CRGBW LED lighting options.



Features:

• Physical dimensions (Diameter x Depth): 176 x 304 mm
• Water and dust rating: IP65
• Configuration: Coaxial
• Peak power (Watts): 6.5": 230 W
• RMS power (Watts): 6.5": 75 W
• Sensitivity (1 W / 1 m): 6.5": 90 dB
• Frequency response: 6.5": 70 Hz-22 kHz
• Nominal impedance: 4 ohms
• Recommended amplifier power (RMS): 6.5": 30-90 W/Ch
• LED lighting: yes (CRGBW)
• LED supply voltage: 10.8-16 VDC
• LED load current @ 14.4 VDC: 300 mA
• Operating temperature range: 0° to 50° C
• Voice coil diameter: 6.5": 1.2"
• Operating temperature range: 0° to 50° C
• Tweeter type: Silk dome
• Compass-safe distance: 6.5": 310 cm
• Warranty: 3 years
