Garmin 10" 600 Watt Sports Chrome

Marine Subwoofer with CRGBW

DESIGNED AND ENGINEERED TO TRUE-MARINE™ STANDARDS

Built on the True-Marine design philosophy from Fusion®, the Signature Series 3 subwoofers have an IP65 rating for protection against dust and water ingress and have been tested to a high level of protection against salt fog, temperature, vibration, and UV.

DESIGNED TO COMPLY WITH ISO 12216

Tested to international standards for pressure and water tightness, the Signature Series 3 subwoofers are designed and built to the highest industry standards for quality and robustness.

THE FINEST MATERIALS AND ACOUSTIC ENGINEERING

The Signature Series 3 subwoofers incorporate premium materials and marine-specific design elements. This communicates not only their premium aesthetics but also their ability to reproduce high-quality audio while out on the water.

POLYPROPYLENE CONE TECHNOLOGY

Defined, high-resolution low-frequency acoustics are a result of the excellent self-damping and bass reproduction from the quality polypropylene cone.

LARGE-DIAMETER VOICE COIL

Delivering an increase in real power and efficiency, the large-diameter voice coil provides a signature sound with wave-rippling bass exclusive to the Signature Series 3 subwoofers.

HIGH-GRADE BASKET CONSTRUCTION

The basket is constructed using high-grade engineered plastics to deliver unprecedented durability when exposed to the marine environment.

PREMIUM CRGBW LED LIGHTING

Industry-first marine subwoofers with CRGBW (cool white, red, green, blue, warm white) illuminate an unprecedented spectrum of colours — from premium pastels to vibrant hues — to enhance your audio entertainment experience.

CONTROLLING THE CRGBW LIGHTING

Control the colour (static or dynamic), brightness, light mode, and speed by using the optional MS-CRGBWRC wireless remote control (sold separately) or from a Garmin multifunction display via OneHelm™ integrated digital switching (lighting partner controller required).

SPORTS WHITE SUBWOOFER

The Signature Series 3 sports white subwoofer is available in a 10-inch size and features industry-first CRGBW LED lighting options.

CLASSIC WHITE SUBWOOFER

The Signature Series 3 Classic subwoofer is available in a 10-inch size and features a timeless, elegantly styled perforated metal grille to blend with the aesthetics of your boat.

SPORTS CHROME SUBWOOFER

The Signature Series 3 sports chrome subwoofer is available in a 10-inch size and features industry-first CRGBW LED lighting options.



Features:

Physical dimensions (Diameter x Depth):  Sports Subwoofer: 10.83" x 6.77" (275 x 172 mm)
Water and dust rating: IP65
Speaker size: 10"
Peak power (Watts): 600 W
RMS power (Watts): 300 W
Sensitivity (1 W / 1 m): 86 dB
Magnetic structure: 68 oz
Frequency response: 30 Hz-2 kHz
Nominal impedance: 4 ohms
Recommended amplifier power (RMS): 50-600 W
LED lighting: Yes - CRGBW (sports-style only)
LED supply voltage: 10.8-16 VDC (sports-style only)
LED load current @ 14.4 VDC: 300 mA (sports-style only)
Operating temperature range: 32° to 122° F (0° to 50° C)
Voice coil diameter: 2"
Cone material: Polypropylene cone with rubber surround
Compass-safe distance: 205" (520 cm)
Warranty: 3 years


Mounting dimensions:


Mounting diameter clearance: 8.78" (223 mm)
Mounting depth clearance: 5.24" (133 mm)



Optimum enclosure recommendations:


Sealed enclosure volume (fully filled with absorption material): 0.6 cubic ft (17.2 L)
Ported (vented) enclosure volume (lined with absorption material): 1.6 cubic ft (45 L)
Port diameter: 4" (104 mm)
Port length: 10.43" (265 mm)

Package Includes:

• One subwoofer (based on what you select)
• Documentation

SKU 010-02435-11
Model # 010-02435-11
Barcode # 753759254742
Brand Fusion
Artist / Author FUSION 10" 600 Watt Sports Chrome Marine Subwoofer CRGBW Garmin 010-02435-11
Shipping Weight 1.8000kg
Shipping Width 0.180m
Shipping Height 0.180m
Shipping Length 0.275m
Shipping Cubic 0.008910000m3
Type FUSION 10" 600 Watt Sports Chrome Marine Subwoofer CRGBW Garmin 010-02435-11
Format FUSION 10" 600 Watt Sports Chrome Marine Subwoofer CRGBW Garmin 010-02435-11
