Lowrance ELITE-9 Ti

TotalScan Combo
Navionics+ Gold Australia wide Mapping card

The Lowrance® Elite-9 Ti is a touchscreen fishfinder/chartplotter that matches popular high-end functions and features with powerful performance ─ all at an affordable price.
Sporting a 9-inch, high-resolution touchscreen display, Elite-9 Ti has your sonar needs covered with support for StructureScan® HD, Low/Med/High CHIRP and the TotalScan™ all-in-one transducer. With built-in C-MAP charts and reliable Lowrance navigation technology, navigation is accurate and easy with Elite-9 Ti. Featuring integrated Bluetooth® and wireless connectivity, Elite-9 Ti allows you to download software updates directly to the unit.
Key Features:
  • High resolution display
  • Lowrance-exclusive,high-resolution, 9-inch, LED-backlit color display
  • Easy-to-use touchscreen
  • Touchscreen provides fast, fingertip access to all Elite-9 Ti features
  • CHIRP Sonar, StructureScan®HD and DownScan Imaging™
  • Top-of-the-line sonar technologies provide the best possible view of the environment beneath your boat. StructureScan® HD requires optional TotalScan™ transducer.
  • TrackBack™
  • Scroll back through your sonar,SideScan or DownScan history to review structure or fish targets and mark the location with a waypoint.
  • InternalGPS antenna
  • Highly accurate, built-in GPS antenna
  • Built-in wireless connectivity
  • Access to the GoFree™ Cloud where you can shop, purchase, download and immediately useInsight maps, and third-party maps from GoFree partners
  • Boat Integration and System Control
  • Bluetooth® control of Power-Pole® shallow water anchors and SmartSteer™ control of Motorguide® Xi5 Trolling Motors
  • microSDcard slot

 photo Lowrance Elite 9 TI Diamenasions Mr Boats_zpsi6rp7tuy.gif

Specifications:

Display

9"/ 228.6 mm (16:9)

Resolution

800 x 480

Power Output: RMS (PTP)

Max 500W RMS

Operating Frequency

(50/200 or 83/200 kHz) + 455/800 kHz

Languages

31 (some available regionally)

Media Port

1 microSD slot

Warranty

One Year

Display

Display Resolution

800W x 480H

Backlighting Type

LED

GPS and Sonar Overlay Data

Yes

Display Size

9"/ 228.6 mm (16:9)

Sonar

Depth Alarm

YES

Shallow Alarm

Yes

Standard Fishfinding Features: COLORLINE™ or GRAYLINE®, ASP™, FishSymbol I.D.™, FishTrack™, and more

Yes

Temperature Readings

Yes

Transducer Type

9-pin Connection, with optional 9-pin to 7-pin adapter; Multiple Selections Lowrance and Airmar


Networking Connectors
NMEA 0183 Interface YES
Technical/Environmental
Operating Temperature -15° C to + 55° C (+ 5° F to + 131° F)
Power

Power Consumption

12 W (0.9 A @ 13 vDC)

Power Supply (Supply Voltage)

12 vDC (10-17 vDC min-max)


GPS Navigation

Navigation: Routes

100

Navigation: Waypoint Storage

3000

GPS Antenna Type

10kHz Internal high-sensitivity WAAS/EGNOS/MSAS

Plot Trails

Up to 100 trails with up to 10,000 points per trail

GPS Alarms

Yes


Other
Languages 31 - Available in regional language packs
Radar
Antenna Type

10kHz Internal high-sensitivity WAAS/EGNOS/MSAS

 photo Lowrance ELITE 9 Ti Touch Squence Mr Boats.jpg copy_zpswp9o1frd.jpg

DOCUMENTS

Package Includes:
  • Elite 9 TI
  • Navionics+ Card
  • Bracket
  • Power Cable
  • TotalScan Transducer
SKU 000-14651-001
Barcode # 9420024154915
Brand Lowrance
Shipping Weight 3.6300kg
Shipping Width 0.320m
Shipping Height 0.220m
Shipping Length 0.220m
Shipping Cubic 0.015488000m3
Unit Of Measure ea
